Edwards Auto 306 e-beam Evaporator

E-beam evaporator recommended for oxide and nitride materials. Designed to operate around the e-5 millibar vacuum range, EE-2 can also be used to deposit metals (non-toxic materials) if very low pressure is not a critical factor in your process. The water-cooled substrate holder can accommodate one wafer up to 3� diameter. EE-2 has a rotary-vane mechanical roughing pump and a turbo high-vacuum pump, and is a relatively low voltage (~3.8kV) electron beam evaporation deposition system with a 4-pocket, water-cooled rotating hearth. [Product Link]

RRID:SCR_019844

cite this instrument

Leica EM ACE600 High Vacuum Sputter Coater

EM ACE600 sputter coater is a versatile high vacuum film deposition instrument for your FE-SEM and TEM applications. [Product Link]

RRID:SCR_020237

cite this instrument

Leica EM AFS2 Freeze Substitution Device

Leica EM AFS2 is a freeze substitution platform that performs freeze substitution and progressive lowering of temperature (PLT) techniques and allows low temperature embedding and polymerization of resins. The Leica EM FSP (freeze substitution processor), an automatic reagent handling system combined with the Leica EM AFS2, dispenses reagents for both freeze substitution and PLT applications. The LED illumination from within the chamber and the attached stereomicroscope for viewing and positioning of samples ensures ease of use. [Product Link]

RRID:SCR_020230

cite this instrument

Leica VT1200S vibrating microtome

Fully automated Leica VT1200 S vibrating blade microtome is designed to meet the highest sectioning demands for cutting fresh and fixed tissue in Neuroscience. To achieve sections of the highest quality that retain viable cells on the section surface, the vertical deflection of the blade can be measured by Leica's Vibrocheck measurement device and minimised with the blade holder. The instrument was designed in collaboration with Prof. Dr. Peter Jonas and his group at the Physiology Department, Freiburg Germany. [Product Link]

RRID:SCR_020243

cite this instrument

Pelco 34700 Biowave Microwave Processor

Laboratory microwave system that includes water recirculation system temperature restrictive temperature probe. It is also capable of variable wattage, programmable times, and four intermittent power settings. [Product Link]

RRID:SCR_018608

cite this instrument

Denton Vacuum Desk IV Sputter Coater

FEI TECNAI G2 Spirit BioTwin Transmission Electron Microscope (120Kv)

with AMT BioSprint29 29 Megapixel camera system, for room temperature or cryo-EM

FEI Vitrobot Mark VI Plunger

GD110 Glow Discharger

JEOL 1400 Plus Transmission Electron Microscope

equipped with STEM, for room temperature or cryo-EM

JEOL JSM-IT500HR Scanning Electron Microscope

Leica ACE600 Sputter Coater

Leica UC6b/EM FC6 Cryoultramicrotome

Leica UC7 Ultramicrotome

Leica VT100S Vibrating Blade Microtome

LKB glass knife-makers

PELCO BioWave Microwave Oven

RMC Boeckeler Powertome PC Ultramicrotome

Tousimis Autosamdri-931 Critical Point Dryer

Wohlwend Compact HP03 High-Pressure Freezer
